該閥組包含兩部分，各由一個單向閥和反向管路先導控制的一個溢流閥組成;單向閥部分允許壓力油自由流入油缸V1→C1(V2→C2)，同時阻止油反向流動保持負載C1→V1(C2→V2);溢流閥部分在先導壓力建立后，可控制執行機構的運動。溢流壓力設置通常高于1.3倍的最大負載壓力，但平衡閥的開啟依靠閥的先導比。該閥通過調節執行器的輸入流量和輸出流量，經C1和C2口提供負載的靜態和動態控制。

The valve group consists of two parts, each composed of a one-way valve and a reverse pipeline pilot controlled relief valve;The check valve section allows the pressure oil to flow freely into the cylinder V1→C1(V2→C2), while preventing the reverse flow of oil to maintain the load C1→V1 (C2→V2).The relief valve part can control the movement of the actuator after the pilot pressure is established. The overflow pressure setting is usually higher than 1.3 times the maximum load pressure, but the opening of the balance valve depends on the pilot ratio of the valve.The valve provides static and dynamic control of the load via ports C1 and C2 by regulating the input and output flow of the actuator.

1.最大工作壓力(Max.0peratingPressure):350bar

2.額定流量(Rated flow):60L/min

3.控制比(Pilot Ratio):4.25:1

4.內泄漏(Internal Leakage): ≤5 drops/min

5.單向閥開啟壓力(Check valve opening pressure):3bar

6.工作溫度(Temperature range):-20~+100℃

7.油液清潔度(Cleaning code):20/18/15(NAS9)

8.閥塊材料(Body Material):steel part zinc-nickel alloys

9.油口尺寸(Oil port size):V1、C2、V2、C2:G1/2 or G3/8

10.每轉壓力變化(Pressure increase bar/turn):27bar
