當P口壓力上升到一定水平，由于閥芯內外的面積差使得該閥芯相當于閥座被打開，P到T開始溢流。該類型的閥反應靈敏，內泄漏小，相對于標準直動式溢流閥壓降比較小，適用于較大流量場合

When the pressure at”p”rises a certain level.Due to the area difference between the inside and outside of the spool.It is opened relative to the valve seat, Starting to overflow from p to T.This type of valve have fast response and low internal leakage,Have a lower pressure drop than the standard directing acting relief valves, Suitable for the larger flow situations.

1.額定壓力(Rated pressure):18bar

2.額定流量(Rated flow):40L/min

3.開啟率(Cracking Rate) ≥38%

4.閉合率(Closing Rate)≥33%

5.內泄漏 (internal Leakage)≤10ml/min at 126 bar

6.油液清潔度(Cleaning code):20/18/15(NAS9)

7.工作溫度(Temperature range):-20~+100℃

8.每轉壓力變化(Pressure change per turn):475bar

9.安裝扭矩(Installation Torque):30~35Nm

10.鎖緊扭矩(Nut Tightening Torque):10~12Nm
